Two-color power plug vertical injection molding machine
| Packaging: | Fumigation wooden box |
|---|---|
| Productivity: | 30/month |
| Brand: | Zanyang |
| Transportation: | Ocean,Land |
| Place of Origin: | China |
| Supply Ability: | 20 Piece/Pieces per Month |
| HS Code: | HS8477101090 |
| Port: | ShangHai,NingBo etc,ShenZhen |
Basic Info
Model No.: Two-color power plug vertical injection molding machine
Product Description
Two-color power plug vertical Injection Molding Machine
1.Upright opening and closing mold with inline screw injection for easy inlay injection molding.
2.Multi-stage PID temperature control of material tube, infinitely adjustable speed of feeding, stable molding.
3.Screen-type industrial control computer, simple operation, precise control low failure.
4.Two-station sliding plate structure, can be used as two machines for independent operation.
5.Double-seat table injection structure, one lower die and two upper dies, sliding left and right in the same plane, can realize two materials or colors in sequence injection molding, greatly improving work efficiency.
| MODEL | UNIT | CY-450STDM-SS | CY-1500STDM-SS | |||||
| INJECTION UNIT | Screw Diameter | mm | 30 | 32 | 35 | 35 | 42 | 48 |
| lnjection Pressure | kg/cm2 | 1171 | 996 | 810 | 2569 | 1888 | 1649 | |
| Theoretical Shot Volume | cm3 | 81 | 92 | 110 | 161 | 232 | 303 | |
| Max.Shot Weight(Ps) | g | 74 | 84 | 106 | 144 | 208 | 273 | |
| Safe Shot Weight(Ps) | OZ | 2.6 | 3.0 | 3.8 | 5.2 | 7.5 | 9.7 | |
| Injection Rate | cm3/sec | 62.5 | 71 | 95 | 95 | 129 | 142 | |
| Screw stroke | mm | 115 | 240 | |||||
| Screw Speed Max. | rpm | 0-190 | 0-180 | |||||
| Nozzle Comtact Force | tons | 4.45 | 4.2 | |||||
| Nozzle Retraction Stroke | mm | 190 | 280 | |||||
| Number of Temperature Control | 3 | 5*2 | ||||||
| CLAMPING UNIT | Clamping Force | tons KN | 45 450 | 150 | ||||
| Sliding block size | mm | 830*400 | 1220*600 | |||||
| Tiebar distance | mm | 410*250 | 620*430 | |||||
| Min.Mold Height | mm | 200/150 | 550/350 | |||||
| Opening Stroke | mm | 200 | 390 | |||||
| Max.Open Daylight | mm | 400/350 | 940/740 | |||||
| Ejetor Force | tons | 1.5 | 6.3 | |||||
| Ejetor Stoke | mm | 135 | 135 | |||||
| POWER/HEADING UNIT | Max.Hydaulic Pressure | kg/cm2 | 140 | 140 | ||||
| Pump Output | l/min | 37.2*2 | 56*2 | |||||
| Oil Resservoir Capacity | l | 180 | 230 | |||||
| Cooling Waer Consumption | l/hr | 600-800 | 800-1000 | |||||
| Pump Motor Power | kW/HP | 5.5/7.5HP*2 | 22/30HP*2 | |||||
| BerrelHeating Power | kW | 2.8*2 | 8.5*2 | |||||
| Total Weight | kW | 18 | 61 | |||||
| OTHER | Machine Weight | tons | 4.2 | 12 | ||||
| Machine Dimensions(LxWxH) | m | 2.5*1.9*3.08 | 3.5*2.6*4.6 | |||||
| Shipping weight | tons | 4.5 | 12.5 | |||||
| Shipping Measurements(LxWxH) | m | 2.6*2*2.3 | 3.7*2.8*3.6 | |||||
Q1:Are you a trading company or a manufactory?
A1:We are a manufactory,can give u best service and low price.
Q2:What's your guarantee or the warranty of the quality if we buy your machines?
A2:We offer you high quality machines with 1 year warranty .
Q3:When can I get my machine after I paid?
A3:We will deliver the machines on time as the date we agreed both side.
